FBN 40SD


ChainNo.40
Pitch(P)12.7 mm  (1/2inch)
Internal width(W)7.95 mm
Roller dia.(Dr)7.95 mm
Tooth width(T)7.2 mm   (C) 27.8　mm


Outside dia.
Do		Pitch dia.
Dp		HubaWeight
(kg)		Sprocket No. Bore dia.
H7
BDBLTypeTeeth No.
5549.07343517.50.33FBN 40SD1215,18
5953.07383517.50.401318,20
6357.07423517.50.491418,20
6761.08463517.50.571520,25
7165.10503517.50.661620,25
7669.12543517.50.761725,28,30
8073.14593517.50.891825,28,30,35
8477.16633517.51.001925,28,30,35
8881.18673517.51.142025,28,30,35
9285.21713517.51.232125,28,30,35


Finished Bore
Bore dia.H7Keyway
bxt2		Setscrewｭｳ
M
15~175X2.36
18~226X2.86
24~308X3.38
32~3510X3.38




FBN 50SD


ChainNo.50
Pitch(P)15.875 mm  (5/8inch)
Internal width(W)9.53 mm
Roller dia.(Dr)10.16 mm
Tooth width(T)8.7 mm   (C) 31.3　mm


Outside dia.
Do		Pitch dia.
Dp		HubaWeight
(kg)		Sprocket No. Bore dia.
H7
BDBLTypeTeeth No.
6961.344340200.63FBN 50SD1218,20
7466.344840200.751320,25,28
7971.345340200.901420,25,28,30
8476.355840201.041520,25,28,30,35
8981.376340201.221625,28,30,35,40
9486.396840201.411725,28,30,35,40
10091.427340201.611825,28,30,35,40
10596.457940201.801925,28,30,35,40
110101.488440201.952025,28,30,35,40
115106.518940202.272128,30,35,40


Finished Bore
Bore dia.H7Keyway
bxt2		Setscrewｭｳ
M
18~226X2.86
24~308X3.38
32~3810X3.38
4012X3.38



FBN 60SD


ChainNo.60
Pitch(P)19.05 mm  (3/4inch)
Internal width(W)12.70 mm
Roller dia.(Dr)11.91 mm
Tooth width(T)11.7 mm   (C) 38.3　mm


Outside dia.
Do		Pitch dia.
Dp		HubaWeight
(kg)		Sprocket No. Bore dia.
H7
BDBLTypeTeeth No.
8373.605150251.14FBN 60SD1220,25,30
8979.605750251.391325,30,35
9585.616450251.631430,35,40
10191.627050251.961530,35,40
10797.657650252.201630,35,40,45
113103.678250252.561730,35,40,45
119109.718850252.901830,35,40,45
126115.749450253.261940,45,50
132121.7810050253.702040,45,50
138127.8210750254.132140,45,50


Finished Bore
Bore dia.H7Keyway
bxt2		Setscrewｭｳ
M
20~226X2.86
24~308X3.38
32~3810X3.38
40~4212X3.38
45~5014X3.810




FBN 80SD


ChainNo.80
Pitch(P)25.4 mm  (1inch)
Internal width(W)15.88 mm
Roller dia.(Dr)15.88 mm
Tooth width(T)14.6 mm   (C) 45.4　mm


Outside dia.
Do		Pitch dia.
Dp		HubaWeight
(kg)		Sprocket No. Bore dia.
H7
BDBLTypeTeeth No.
11098.146960302.52FBN 80SD1235,40,45
118106.147760303.041340,45,50
127114.158560303.601440,45,50
135122.179360304.161540,45,50
143130.2010260304.891640,45,50,60
151138.2311060305.611740,45,50,60
159146.2711860306.361840,45,50,60
167154.3212660307.131940,45,50,60
176162.3713460308.032040,45,50,60
184170.4214260308.882140,45,50,60


Finished Bore
Bore Dia H7 Keyway
bxt2		Setscrewｭｳ
M
32~3810X3.38
40~4212X3.38
45~5014X3.810
5516X4.312
6018X4.412
