Chain
size |
Links
Per
10' |
Wt.
Per
10' |
Min
Adv.
Tensile
Strength |
Pitch
P |
Pin
Dia.
φ |
Inside
Width
C |
Height
H |
Thickness
T |
Overall
Width
B |
| 205 |
96 |
3.9lbs. |
2800lbs. |
1.250 |
0.200
|
0.375 |
0.470
|
0.080 |
0.844
|
| 662 |
72 |
10.5lbs |
8,500lbs. |
1.640 |
0.281 |
0.906
|
0.720
|
0.125
|
1-5/8 |
| 667H |
52 |
11.7lbs. |
9,500lbs. |
2.313 |
0.312
|
1.000
|
0.875
|
0.125
|
1-47/64 |
| 667X |
53 |
18.6lbs. |
15,000lbs. |
2.250 |
0.437 |
1-1/16 |
0.937
|
0.170
|
1-61/64 |
| 667XC |
53 |
21.0lbs. |
18,000lbs. |
2.250 |
0.437 |
1-1/16 |
0.937 |
0.170 |
1-61/64 |
| 667K |
53 |
24.4lbs. |
20,000lbs. |
2.250
|
0.437 |
1-5/64 |
1.062
|
0.200 |
2-1/8 |
| 667KC |
53 |
25.6lbs. |
24,000lbs. |
2.250
|
0.437 |
1-5/64 |
1.062
|
0.200 |
2-1/8 |
| 667XH |
53 |
28.0lbs. |
28,000lbs. |
2.250
|
0.469
|
1-5/64 |
1.062
|
0.224 |
2-5/16 |
| 88K |
46 |
23.0lbs. |
20,000lbs. |
2.609 |
0.437
|
1-5/64 |
1.062
|
0.200 |
2-1/8 |
|
| |
| |
|
|
Chain
size |
CC |
Length
Links |
Conve Yor
Bar
Qty |
Width
B |
Thickness
T |
| 662-59P |
10.563
|
59 |
19 |
1 |
3/16 |
| 662-131P |
10.563
|
131 |
43 |
1 |
3/16 |
| 662-121P |
10.500
|
121 |
40 |
1 |
1/4 |
| 662-123P |
10.025
|
123 |
41 |
3/4 |
3/16 |
| 662-150P |
14.024 |
150 |
50 |
3/4 |
3/16 |
| 667X-98P |
15.000
|
98 |
33 |
3/4 |
1/2 |
| 667X-120P |
15.000 |
120 |
40 |
3/4 |
1/2 |
| 667X-112P |
18.250
|
112 |
| 56 |
1-1/4 |
3/8 |
| 667X-144P |
14.000
|
110 |
129 |
1 |
1/4 | |
| |
| |
|
|
| Chain |
Average
Pitch
Inches |
Average
Ultimate
Strength
Lbs. |
Rated
Working
Load
Lbs. |
Approx
Links
in
10 Feet
|
Average
Weight
Per
Foot
|
DIMENSIONS IN
INCHES |
Overall
Width
|
Length
of
Bearing |
Rivet
Dia. |
Side
Bar
Thickness |
Side
Bar
Width |
Barrel
Dia. |
Max
Spkt.
Face |
| JK |
X |
D |
T |
F |
H |
A |
| WR78 |
2.609 |
19,000 |
3,000 |
46 |
4.0 |
3 |
2 |
1/2 |
1/4 |
1-1/8 |
7/8 |
1-1/8 |
| WH78 |
2.609 |
28,700 |
3,000 |
46 |
4.0 |
3 |
2 |
1/2 |
1/4 |
1-1/8 |
7/8 |
1-1/8 |
| WR82 |
3.075 |
20,600 |
3,800 |
39 |
4.8 |
3-1/4 |
2-1/4 |
9/16 |
1/4 |
1-1/4 |
1-1/16 |
1-1/4 |
| WR82 |
3.075 |
30,300 |
3,800 |
39 |
4.8 |
3-1/4 |
2-1/4 |
9/16 |
1/4 |
1-1/4 |
1-1/16 |
1-1/4 |
| WR124 |
4.000 |
45,500 |
6,200 |
30 |
8.3 |
4-1/4 |
2-3/4 |
3/4 |
3/8 |
1-1/2 |
1-3/8 |
1-1/2 |
| WR124 |
4.000 |
67,000 |
7,200 |
30 |
8.3 |
4-1/4 |
2-3/4 |
3/4 |
3/8 |
1-1/2 |
1-3/8 |
1-1/2 |
| WR110 |
6.000 |
45,500 |
6,750 |
20 |
7.2 |
4-5/8 |
3 |
3/4 |
3/8 |
1-1/2 |
1-3/8 |
1-7/8 |
| WR110 |
6.000 |
45,500 |
6,750 |
20 |
7.2 |
4-5/8 |
3 |
3/4 |
3/8 |
1-1/2 |
1-3/8 |
1-7/8 |
| WR132 |
6.050 |
78,000 |
13,000 |
20 |
14.2 |
6-1/4 |
4-3/8 |
1 |
1/2 |
2 |
1-3/4 |
2-7/8 |
| WR132 |
6.050 |
111,000 |
15,300 |
20 |
14.2 |
6-1/4 |
4-3/8 |
1 |
1/2 |
2 |
1-3/4 |
2-7/8 |
| WR150 |
6.050 |
78,000 |
13,000 |
20 |
16.8 |
6-1/4 |
4-3/8 |
1 |
1/2 |
2-1/2 |
1-3/4 |
2-7/8 |
| WH150 |
6.050 |
112,000 |
15,300 |
20 |
16.8 |
6-1/4 |
4-3/8 |
1 |
1/2 |
2-1/2 |
1-3/4 |
2-7/8 | |
| |
| |
|
|
Chain
No. |
Average
Pitch
Inches |
Approx
Links
in
10
Feet |
DIMENSIONS IN
INCHES |
Overall
Width
|
Length
of
Bearing |
Rivet
Dia.
|
Side
Bar
Thickness |
Side
Bar
Width |
Barrel
Dia.
|
Max
Spkt.
Face |
| JK |
X |
D |
T |
F |
H |
A |
| C55 |
1.631 |
74 |
1-312 |
1-1/4 |
3/8 |
3/16 |
3/4 |
232 |
11/16 |
| C55L |
1.631 |
74 |
1-312 |
1-1/4 |
3/8 |
3/16 |
3/4 |
232 |
11/16 |
| C60 |
2.307 |
52 |
2-7/8 |
1-11/16 |
1/2 |
1/4 |
1 |
3/4 |
7/8 |
| C77 |
2.307 |
52 |
2-1/4 |
1-1/4 |
7/16 |
3/16 |
7/8 |
232 |
11/16 |
| C110 |
6.000 |
20 |
4-3/8 |
2-7/8 |
5/8 |
3/8 |
1-1/2 |
1-1/4 |
1-15/16 |
| C111 |
4.760
|
25 |
5 |
3-3/8 |
3/4 |
3/8 |
1-3/4 |
1-7/16 |
2-3/8 |
| C131 |
3.075
|
39 |
3-1/2 |
2-1/16 |
5/8 |
3/8 |
1-1/2 |
1-72 |
1-1/8 |
| C132 |
6.050
|
20 |
6-1/2 |
4-5/16 |
1 |
1/2 |
2 |
1-232 |
3-1/8 |
| C188 |
2.609
|
46 |
1-1/8 |
1-9/16 |
1/2 |
1/2 |
1-1/8 |
7/8 |
15/16 | |
| |
| |
|
|
Att.
No. |
Chain
No. |
Dimensons |
| E |
J |
K |
N |
T |
S |
R |
| SF |
662 |
- |
3-35/64 |
5-1/4 |
21/64 |
0.105 |
1-1/2 |
0.720 |
| SF |
662H |
2 |
3-1/2 |
8-3/8 |
21/64 |
0.105 |
2-72 |
0.787 |
| SF |
667H |
2 |
3-1/2 |
8-3/8 |
21/64 |
0.105 |
2-72 |
0.875 | |
| | | | |
